Hasselblad X1D-50c User Manual

X1D Table of Content www.hasselblad.com
USER GUIDE
10
Introduction
1.4 X1D TECHNICAL SPECIFICATIONS
Camera Type Medium Format Mirrorless Digital camera with Autofocus, Auto exposure, interchangeable Lenses.
Construction Machined aluminium. Tripod socket 1/4”.
Sensor Type CMOS, 50 mega pixels (8272 × 6200 pixels, 5.3 × 5.3 µm).
Sensor Dimensions 43.8 × 32.9 mm.
Image Size Stills: RAW 3FR capture 106 MB on average. TIFF 8 bit: 154 MB; Video: HD (1920 x 1080p, max 5 minutes/clip).
File Format
Stills: Hasselblad 3FR.
Video: H.264 Compressed (25 fps).
Shooting Mode Single shot stills, Video. Interval Timer and Exposure Bracketing.
Colour Denition 16 bit; Dynamic range approximately 14 stops.
ISO Speed Range ISO Auto, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600.
Storage Options Two SD cards or tethered to Mac or PC. SD Cards can be used in Overow or Backup mode.
Colour Management Hasselblad Natural Colour Solution, HNCS.
Storage Capacity 16 GB card holds 120 images on average.
Capture Rate 1.7 frames per second (2.0 in M and MQ Mode).
User Interface
Touch functionality: Yes, full support. Touch interface including swipe, scroll and pinch/spread to zoom. Camera grip with buttons and
Scroll Wheels. Many camera functions and settings can be controlled from a tethered computer or iPhone/iPad over Wi-Fi.
Display 3 inch TFT type, 24 bit colour, 920 K pixels.
Live View On camera, host and iOS device with high frame rate.
Viewnder (EVF) 2.4 Mega-pixel Electronic Viewnder (EVF).
Histogram Feedback Yes, in Browse Mode on rear display and in EVF.
IR Filter Mounted in front of sensor.
Software Phocus for Mac and Windows. Compatible with Adobe Camera and Adobe Photoshop Lightroom.
Platform Support Macintosh: OS X version 10.9. PC: XP/Vista/Windows 7 (32 and 64 bit)/ 8 / 10.
Host Connection Type USB 3.0 (5 Gbit/s) Type-C connector.
Additional Connections Mini HDMI, Audio In/Out.
Operating Temperature -10 to 45 ˚C. 14 to 113 ˚F.
Wi-Fi 802.11 b, g, n, a, ac (a and ac depending on region).
Dimensions Complete camera w/ XCD 45 mm lens: 148 x 97 x 125 mm [W x H x D].
Weight 1170 g (Complete camera with XCD 45 mm lens, Li-Ion battery and card).
Lenses
Hasselblad XCD lenses with built in electronically controlled shutter and aperture. Automatic or manual focusing with instant manual
focus override. All HC/HCD lenses can be used with an adapter (optional). Lens shades can be mounted in reverse for transport.
Shutter Electronically controlled lens shutter with speeds up to 1/2000. Flash sync at all speeds. Optional Electronic shutter
Shutter Speed Range 68 minutes to 1/2000 seconds with XCD lenses. 1/800 or 1/2000 with HC/HCD lenses. Electronic shutter 68 min to 1/10000.
Flash Sync Speed Flash can be used at all shutter speeds.
Flash Control
TTL centre weighted system. Compatible with Nikon
TM
System ashes. ISO range 100 to 6400. Flash output can be adjusted (-3 to
+3 EV) for ll-in purposes independent of ambient light. Sync at all shutter speeds.
Flash Compatibility In TTL-mode, the following Nikon Flash products can be used: SB-300, SB-500, SB-700, SB-900, SB-910.
Focusing
Automatic and manual focusing. Instant manual focus override. Automatic focusing using contrast detection. 100% zoom possible in
manual focus.
Exposure Metering
Spot, centre weighted and centre spot.
Metering range. Spot: EV 2 to EV 21. Centre weighted: EV 1 to EV 21. Centre spot: EV 1 to EV 21.
Power Supply Rechargeable Li-ion battery (7.2 VDC/3200 mAh).
GPS External Module 72-channel u-blox M8 engine supporting GPS L1C/A, SBAS L1C/A, QZSS L1C/A, GLONASS L1OF and Galileo E1B/C1.

Hasselblad X1D-50c Specifications

General

Megapixel	50 MP
Camera type	MILC
Image stabilizer	-
Image sensor size	- \
Image formats supported	JPEG
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	8272 x 6200
Optical zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 12800, 25600
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Video recording	Yes
Maximum video resolution	1920 x 1080 pixels
Memory slots	2
Compatible memory cards	SD
Maximum memory card size	16 GB
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
USB version	3.2 Gen 1 (3.1 Gen 1)
HDMI connector type	Mini
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	- s
Product color	Black, Grey
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	3200 mAh

Weight and Dimensions

Depth	98 mm
Width	150 mm
Height	71 mm
Weight	725 g
