Hauck BCS 6000C - Appendix B: Configuration Record

Page 20
BCS6000C-9
APPENDIX B: CONFIGURATION RECORD
Factory set default values are shown in parenthesis, e.g.,(1.0)
MAIN MENU SCREEN
PLC PROGRAM: __________
SCREEN PROGRAM: __________
MOTOR CALIBRATION & SETUP SCREEN
MOTOR ZERO SPAN DEADBAND
AIR
(1.0)
GAS
(1.0)
OIL
(1.0)
BURNER OUTPUT LIMIT: (100.0)__________
GAS PRESSURE: (24.0) __________ oz.
MATERIAL TEMPERATURE BIAS: (0.0) __________
STACK TEMPERATURE BIAS: (0.0) __________
CONTROL LOOP TUNING SCREEN
MATERIAL STACK DRAFT
GAIN
(2.00) (2.00) (1.25)
DEADBAND
(1) (1) (0.02)
RESET
(1.00) (1.00)
RATE
OPEN CYCLE
(1.00)
CLOSE CYCLE
(1.00)
FILTER
(1)
RUN MENU SCREEN
START AT (30.0) ______ % THEN
RAMP AT (20.0) ______ % PER MIN
LOW FIRE DRIVE IF STACK GREATER THAN (380) ______
LOW FIRE DRIVE IF MATERIAL GREATER THAN (400) ______
PURGE SETPOINT: (0.5) ________ "WC
LOW FIRE SETPOINT: (0.2) __________ "WC
HIGH FIRE SETPOINT: (0.4) __________ "WC
SETPOINT TRANSFER DELAY: __________ SEC
REDUCE DRAFTBY (0) ______ "WC
IF DRAFT DROPS BELOW (0) ______ "WC
MORE THAN (10) ______ TIMES
BIAS POINTS
Firing
Mode
Light
Off
Low
Fire
1
10%
2
20%
3
30%
4
40%
5
50%
6
60%
7
70%
8
80%
9
9%
10
100%
Gas
(5.0) (5.0) (10.0) (20.0) (30.0) (40.0) (50.0) (60.0) (70.0) (80.0) (90.0) (100.0)
Oil or
LP
(3.0) (0) (5.0) (10.0) (15.0) (25.0) (35.0) (45.0) (55.0) (65.0) (77.0) (100.0)
