Haussmann RL - WIRING COLOR CODE

2-10 RefRigeRation / electRical
P/N 0387183_V
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
WIRING COLOR CODE
Leads for all electrical circuits are identied by a colored plastic band: neutral wire for each
circuit has either White insulation or a White plastic sleeve in addition to the color band.
Pink ........... RefRig. theRmostat low temP. oRange oR
light Blue . RefRig. theRmostat noRm temP. tan.............lights
DaRk Blue . DefRost teRm. theRmostat maRoon ......RecePtacles
PuRPle ....... anti-sweat heateRs Yellow* .....DefRost heateRs, 120V
BRown ....... fan motoRs ReD* ...........DefRost heateRs, 208V
gReen* ....... gRounD
*eitheR coloReD sleeVe oR coloReD insulation
ELECTRICIAN NOTE: Use copper conductor wire only.
CASE MUST BE GROUNDED
these aRe maRkeR coloRs wiRes maY VaRY.
Terminal block NOT for case-to-case wire
connection.
