INSTALLATION
TOOL LIST
Unloading From Trailer:
Lever Bar (also known as a Mule,
Johnson Bar, J-bar, Lever Dolly,
and pry lever)
Moving Dolly
Setting Case Line-Up:
Level, 4 ft suggested
Ratchet
¼ in. Socket
5
/16 in. Socket
½ in. Socket
Battery Drill/Screw Gun
Caulking Gun
10 in. Adjustable Crescent Wrench
ANSI Z535.5 DEFINITIONS
• DANGER – Indicate[s] a hazardous
situation which, if not avoided, will
result in death or serious injury.
• WARNING – Indicate[s] a hazardous
situation which, if not avoided, could
result in death or serious injury.
• CAUTION – Indicate[s] a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
• NOTICE – Not related to personal injury –
Indicates[s] situations, which if not avoided,
could result in damage to equipment.
REVISION HISTORY
REVISION V — FEBRUARY 2017
1. Page 1-1, Added Additional Statement to Fed.
/ State Regulations; Ambient Conditions note,
Page 4-1
REVISION U — DECEMBER 2016
1. Page 1-24, Added Splashguard Brackets for
RMT
REVISION T — AUGUST 2016
1. Page 1-6 new diagram and note: “Bottom front
supports must be shimmed if not in full contact
with the floor.”
REVISION S — APRIL 2016
1. PAGE 1-1 Revised UL, PAGE 2-5 Valve
Adjustment
2. Updated text and drawings to add RMTM
nomenclatures, revised size of joining gasket
REVISION R — JULY 2015
1. Replaced RLT drawings in Section 1;
New Drawing Page 2-6, 2-7, 4-2, wording
on 6-2 and 6-4, removed drawing 6-4.
Updated heater replacement, 6-5
REVISION Q — MAY 2015
1. Redesigned manual to 1/2 letter size
REVISION P — OCTOBER 2014
1. California Warning Statement, Page 1-2;
changed to 2 in. partition kit, Page 1-7;
Shim location, Page 1-6; End Caps, Page 1-8;
Removed screws, Page 2-2; Time Termination,
Page 2-8, 2-9; No thread sealer, Page 3-2, 3-3;
RLT load limit drawing, Page 4-2; Ammonia
cleaners, Page 5-3; Number 11, Page 6-1, 6-2;
Heater drawings, Page 6-4, 6-5; Removed
number 2 teflon tape, Page 6-7.
!
!
!
