Hayter RT380H User Manual

1
InstallingtheFrontWheels
Partsneededforthisprocedure:
2Frontwheels
2
Shimwashers(asrequired)
2Flatwashers
2
Cotterpins
2Hubcaps
Procedure
1.Installtheshimwashersontotheaxle.
2.Installthewheelontotheaxlewiththevalvestem
facingout.
3.Slidetheatwasherontotheaxle(Figure3).
Figure3
1.Flatwasher3.Hubcap
2.Cotterpin
4.Insertthecotterpinthroughtheaxleandbendthe
endsofthepinapart(Figure3).
Note:Ifthecotterpindoesnott,removethe
shimwasher(s)asneeded.
5.Pushthehubcap(Figure3)ontotheendoftheaxle.
6.Repeatsteps1through5ontheoppositesideof
thetractor.
7.Greasethewheelbearingsuntilthegreasecomesout
ofthebearingsealarea.
2
CheckingtheTyrePressure
NoPartsRequired
Procedure
Ensurethattheairpressureinthefrontandreartyres
are20psi(138kPa).Checkthepressureatthevalve
stem(Figure4).
Figure4
1.Valvestem
3
InstallingtheSteeringWheel
Partsneededforthisprocedure:
1
Steeringwheel
1
Spirolpin
Procedure
1.Movethefrontwheelssothattheyfacestraight
ahead.
2.Slidethesteeringwheeloverthesteeringshaftand
lineuptheholeinthesteeringwheelwiththeholein
theshaft(Figure5).
Note:Fromtheseatyoushouldbeabletoreadthe
brandlogoonthesteeringwheel.
11
