InstallingtheAnti-Scalp
Wheels
Partsneededforthisprocedure:
2Anti-scalpwheels
2Wheelbolt
2Locknut
Procedure
Mounttheanti-scalpwheelsontothewheelbrackets
withthewheelboltsandlocknut(Figure9).
Figure9
1.Wheel3.Locknut
2.Wheelbracket4.Wheelbolt
Note:Usethesameholeheightonbothsides.
8
PreparingtheCutterDeck
DischargeChute
NoPartsRequired
Procedure
1.Removetherollpinfromthedischargechutespring
anddiscardthepin.
Note:Therollpinisforshipmentonly
2.Ensurethatthespringreturnsthedischargechute
tothefulldownposition.
9
LubricatingtheTractor
NoPartsRequired
Procedure
Ensurethatallofthenecessarypointsonthetractorare
lubricated;refertoGreasingandLubricatingtheTractor
inMaintenance.
10
CheckingtheSafetyInterlock
System
NoPartsRequired
Procedure
Checkthesafetyinterlocksystem;refertoTestingthe
SafetyInterlockSysteminOperation.
11
PurgingtheHydroTransaxle
NoPartsRequired
Procedure
Shippingandhandlingcanintroduceairintothehydro
transaxle.Forproperperformance,removeallthe
trappedair.
1.Movethetractortoaat,levelsurface
2.PlacethedrivecontrolinthePushposition
(Figure10).
