U10M, U10S
32
A1385-6.2 en/de/frHBM
Nominal (rated)
force
500250125502512.552.51.25kNF
nom
Limit bending
moment
5)
M
b
perm
N@m 30 60 125 315 635 1270 3175 5715 11430
Limit torque
5)
M
L
N@m 30 60 125 315 635
4)
1270 3175 5715 11430
Nominal (rated)
displacement
s
nom
mm
0.02 0.03 0.04 0.05 0.06
Fundamental
resonance
frequency
f
G
kHz 4.5 5.9 9.3 6.6 9.2 6.5 8.1 6.6 6.1
Rigidity
F/S 10
5
N/mm
0.625 1.25 2.5 4.17 8.33 16.7 31.3 50.0 83.3
Permissible
vibrational stress
(Vibration bandwidth
per DIN 50100)
F
rb
% v.
F
nom
200
Weight (without
cable)
with adapter
without
adapter
kg
lbs
kg
lbs
1.2
2.65
0.5
1.1
3
6.61
1.3
2.87
10
22.05
5
11.02
23
50.71
11
24.25
60
132.28
28
61.73
Immunity from interference
(EN 61326-1, Table A.1)
Industrial environment
Electromag. field (AM)
Magnetic field
Electrostatic discharge (ESD)
Contact discharge
Air discharge
Burst
(rapid transients)
Surge
(impulse voltages)
Grid‐bound interferences (AM)
V/m
A/m
kV
kV
kV
KV
V
10
30
4
8
1
1
3
Mechanical shock
(Test severity level IEC
68-2-29-1987)
1000
3
1000
Number
Duration
Acceleration
n
ms
m/s
2
Vibrational stress
(Test severity level per DIN IEC
68; Part 2-6;
IEC68-2-6-1982)
Frequency range
Duration
Acceleration
Hz
min
m/s
2
5  65
30
150
Degree of protection per DIN
EN 60529
IP64 / IP67 / IP68
6)
1)
Option: Adjustment of sensitivity to 2 mV/V (or 1 mV/V).
2)
Reversibility error at 200% is typically the same as at nominal (rated) force.
3)
Pure lateral force relating to the link centre of the transducer.
4)
For transducer with adapter: 370 N@m.
5)
See Chapter 5.2.
6)
IP67 for version with bayonet locking (and inserted plug) and for versions with fixed cable and nominal
(rated) force x5 kN. The versions with fixed cable and nominal (rated) force y12.5 kN are IP68, all other
versions are IP64.
