HBM U10M - Accessories - Knuckle Eyes

U10M, U10S
40
A1385-6.2 en/de/frHBM
Nominal
(rated) force
ROSØHGØFDimen‐
sions in
250
mm 95.5
M42x2-4H
95.5 162.3 217.3 160
inch 3.76 3.76 6.39 8.56 6.3
500
mm 122.2
M72x2-4H
135 230.1 307.3 400
inch 4.81 5.31 9.06 12.1 15.75
10.4 Accessories - Knuckle eyes
ZGUW / ZGAM
G
X
V
Dimensions (in mm; 1 mm = 0.03937 inches)
Center of
bearing
collar
Nominal
(rated) force
Knuckle eye
Order number
A jB D F G M V W X Weight
1.25 kN - 25kN 1-Z4/20kN/ZGUW 41.7 16
+0.018
42 67.7 88.7 M16 0 21 15 0.2 kg
50 kN - 125 kN 1-ZGAM33F 35 50
0.012
115 118 182.5 M33x2 7 35 28 2.5 kg
250 kN 1-ZGAM42F 45 60
0.015
126 134 202 M42x2 5 44 36 3.8 kg
500 kN 1-ZGAM72F 45 90
0.02
190 178 280 M72x2 7 60 50 12.6 kg
