HBM U10M - 1 Scope of Supply and Equipment Variants

9
U10M, U10S
A1385-6.2 en/de/fr HBM
1 Scope of supply and equipment variants
 Force transducer U10M (metric internal thread) or
U10S (UN/UNF internal thread)
 U10M/U10S mounting instructions
 Test certificate
 Machine handles for handling use on variants 225 kN to 500 kN
Accessories (not included among the items supplied):
Cables/plugs Order number
Connection cable KAB157-3; IP67 (with bayonet locking); 3 m long, TPE outer
sheath; 6 x 0.25 mm
2
; free ends, shielded, outside diameter 6.5 mm
1-KAB157-3
Connection cable KAB158-3; IP54 (with screw locking); 3 m long, TPE
outer sheath; 6 x 0.25 mm
2
; free ends, shielded, outside diameter 6.5 mm
1-KAB158-3
Loose connecting socket (bayonet locking) 3-3312.0382
Loose connecting socket (screw locking) 3-3312.0354
Ground cable (400 mm long) 1-EEK4
Ground cable (600 mm long) 1-EEK6
Ground cable (800 mm long) 1-EEK8
Knuckle eye, M16 external thread 1-Z4/20kN/ZGUW
Knuckle eye, M33x2 external thread 1-ZGAM33F
Knuckle eye, M42x2 external thread 1-ZGAM42F
Knuckle eye, M72x2 external thread 1-ZGAM72F
Knuckle eye, M16 internal thread 1-Z4/20kN/ZGOW
Knuckle eye, M33x2 internal thread 1-ZGIM33F
Knuckle eye, M42x2 internal thread 1-ZGIM42F
Knuckle eye, M72x2 internal thread 1-ZGIM72F
Equipment options
All force transducers are available in different versions. The following options
are available:
1. Without adapter
You can purchase the force transducer without adapter. The force trans
ducer can then be directly screwed onto a structural element using the
pitch circle, see Fig. 1.1 on Page 10.
