www.goldfitness.com.au.
2
TOOLS:
5# ALLEN WRENCH 5mm 1pcs、
WRENCH W/SCREW DRIVERS=13、14、15 1pcs
Note: Do not plug into the mains power before completing the assembly
ASSEMBLY STEP 1：
ASSEMBLY STEP 2:
ASSEMBLY STEP 3:
Lift up the computer section and upright
posts as arrow direction.
Notice: When you insert the pole
sections ensure that the wires do not
get caught and become damaged.
Slide left upright (3) onto MAIN FRAME
(1)
To attach the upright posts (3) to the
frame use bolt (41) and lock washer (60)
using the 5# Allen wrench
Note: Support the Left upright with your
hand to avoid injury.
Open the carton and remove all foam and
cardboard packaging. Place the treadmill on
the ground as per diagram.
To Next Page
