Heath Zenith 5411 - Testing and Adjustment Procedures; Initial Power Up and Calibration; Setting Controls for Testing; Sensor Aiming and Coverage Area

4
595-4884-22
150°
70ft.
(21m)
8ft.
(2.4m)
Maximum Range Maximum
Coverage Angle
NOTE:Ifxtureismountedhigherthan8ft.(2.4m),aim-
ingthesensordownwillreducecoveragedistance.
Thedetectorislesssensitivetomotiondirectlytowardsit.
3. Loosentheclampscrewinthe
sensor ball joint and gently
rotatethesensor.
4. Walk through the coverage
area noting where you are
whenthelightsturnon(also,
theLEDwillashseveraltimes
whenmotionisdetected).Move
thesensorheadup,down,or
sidewaystochangethecover-
agearea.Keep the sensor at
least 1" (25 mm) away from
the bulbs.
5. AdjusttheRANGEasneeded.
RANGE set too high may
increasefalsetriggering.
6. Secure the sensor head by
tightening the clamp screw.
Donotovertightenthescrew.
7. SettheamountofTIMEyouwantthelightstostay
onaftermotionisdetected(1,5,or10minutes).
Bottom of Sensor
Avoid aiming the control at:
•Objects that change temperature rapidly, such as
heating vents and air conditioners.These heat
sourcescouldcausefalsetriggering.
•Areaswherepets or trafficmaytriggerthecontrol.
•Nearby large, light-colored objectsreectinglight
maytriggertheshut-offfeature.Donotpointother
lightsatthesensor.
Clamp
Screw
Ball
Joint
Aim Sensor
Down for Short
Coverage
Aim Sensor
Higher for Long
Coverage
Least Sensitive Most Sensitive
WARNING: Risk of fire. Do not aim the bulbs
at a combustible surface within 3 ft. (1 m).
TEST AND ADJUSTMENT
1. Turn on the circuit breaker and light switch.
NOTE: Sensor has a 1
1
/
2
 minute warm up period
beforeitwilldetectmotion.Whenrstturned
on,wait1
1
/
2
minutes.
NOTE:MeetstheENERGYSTAR
®
guidelineswhenused
with120WMaxbulbs.
2. Turnthe RANGE control to the medium position
(halfwaybetweenMINandMAX)andtheON-TIME
controltotheTESTposition.
Motion Motion
Sensor
RANGE
1051TEST
ON-TIME
MIN MAX
IMPORTANT: WhenusingaCFLbulb,itisrecommend-
edtousethemaximumON-TIMEsetting.Frequent
ON/OFFcyclingofthebulbwillreduceitslife.
