Heath Zenith 7797 - Tune Settings for Chime Type B; Tune Settings for Chime Type C

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501
6
Push Button Chime < C > 2-Sounds
Chime
3-Sounds
Chime
Jumper - ON Jumper 8 or
Switch 8 - OFF
Ding Ding
Jumper - OFF Jumper 8 or
Switch 8 - OFF
Ding-Dong Ding-Dong
Jumper - OFF Jumper 8 or
Switch 8 - ON
Ding-Dong Westminster
Jumper - ON Jumper 8 or
Switch 8 - ON
Ding Ding
Tune Setting Table – Chime < C > and Push Button Settings*
*For musical chimes, refer to the chime manual when selecting tune.
Push Button Chime < B > 2-Sounds
Chime
3-Sounds
Chime
Jumper - ON ——— Ding Ding
Jumper - OFF Push button on
chime to select
tune
Ding-Dong Ding-Dong or
Westminster
Tune Setting Table – Chime < B > and Push Button Settings*
*For musical chimes, refer to the chime manual when selecting tune.
