Temperature Probe
Principles
The temperature probe is how the Electronic Controller reads the temperature of the water
in the water jacket.
Removal and Replacement
1. Turn off the main power supply to the HEATMOR™.
2. Remove the cover of the low voltage junction box.
3. Pull the temperature probe out of the well.
4. Install the new temperature probe into the well.
5. Disconnect the wires in the low voltage junction box for
the old temperature probe and connect the wires for the
new temperature probe.
6. Replace the cover on the low voltage junction box
