Heatmor 200X - Catalytic Converter Removal and Replacement

69
Removal
There are no nuts or bolts that need to be removed in order for the catalyst to be removed
from the stove. The catalyst is wedged into the ue opening using gravity.
• Remove permanent ash screen by pushing up, then pulling down and forward.
• Remove catalyst holder by pushing one end up and out, then pull down the opposite
end of the catalyst holder. It should angle down and slide out of the ue opening.
Some insulation (Cerawool) may come down when the catalyst is removed. Keep this
to block the gaps between the catalyst and the stove.
• To Replace, angle one end of the catalyst holder up into the ue opening.
• Rotate up the opposite end to swing up into the ue opening.
• Pull both ends down evenly to seat the catalyst in place.
• Insert insulation in gaps between catalyst and stove.
