EXPLODED VIEW
1
Top cover
11
Wired controller
2
Electrical box
12
Compressor
3
Support frame
13
4-way valve assembly
4
Evaporator
14
Right panel
5
Left panel
15
Handle
6
Fan bracket
16
Titanium heat exchanger
7
Fan motor
17
Gas gauge
8
Fan blade
9
Grill
10
Front panel
