• Standard accessories are subject to change without notice.
• This product requires assembly. The product must be assembled correctly before use.
ASSEMBLY
CAUTION! A
Machine must be disconnected from the power supply during parts installing, adjusting,
cleaning, maintenance or when not in use. Disconnecting of the machine from the power
supply reliably prevents random startup, which could cause serious injury.
LOG TRAY
• Remove the protective transport packing from the piston (if used) (fig. 2).
• Screw the work table support and the support leg. (fig. 3)
• Don‘t tighten the screws.
STEEL GUARD
• Join the individual parts of the workspace cover as shown in the picture. (fig. 4)
• First, connect the side cover to the rear cover with three screws.
• Then connect the top cover to the rear with five screws and then the top cover to the side
cover with two screws.
• Finally, connect the front cover to the top using four screws.
• Install the assembled cover on the machine as shown in the figure. (fig. 5)
• Install the work table on the supports with two screws
• Tighten all screws. (fig. 6)
MACHINE INSTALLATION
C This machine shall only be operated at a location meeting the following conditions:
- Level, non-slip ground
- dry place protected from rain and weather
Place the machine on a horizontal substrate (table, rack, etc.) where there are no other objects
and obstacles that could restrict the operator’s free operation and movement while working.
The substrate must be perfectly balanced to prevent slipping and the machine falling during operation.
The substrate’s ideal height is 60-75 cm. Never work with the machine directly on the ground.
Note: I
Ideally, screw the splitter firmly to the base / pedestal using the holes in the splitter’s legs
CAUTION! A
It‘s necessary to carry out check of the oil level before commissioning.
CHECK / POUR HYDRAULIC OIL
• Install the wedge splitter with the oil drain screw facing upwards, unscrew the screw and
pull the dipstick out
• Wipe the dipstick and slide it back into the drain hole.
• Remove the dipstick and check the oil level. The oil trail must be between the MAX and MIN
marks on the dipstick.
(fig. 7)
