6.4.2.2 Boost Pressure Sensor with Housing and Terminal Strip
Am Haselbach 1
D-79677 SchÎnau/Schw.
Germany
Phone: (07673) 8208-0
Telefax: (07673) 8208-88
GmbH + Co.
HEINZMANN
R
10
4,5
52
57
27,5
14
80
113
125
6
91
29,5
SW 24
G3/8" G1/4"
15
30
30
Fig. 7: Boost pressure sensor with housing
Pressure Sensor
EDV- No.
Max. Operating
Pressure (bar rel.)
DSG 04 - 2
600-00-056-00
2
DSG 04 - 5
600-00-056-01
5
DSG 04 - 10
600-00-056-02
10
