9 Actuators
Digital Governor Basic System PANDAROS III 29
9.3 Specification
StG 16 - 01
StG 30- 01
StG 40 - 01
Effective rotation at
output shaft
42°
Max. torque at governor
output shaft
approx. 15 Nm
approx. 28 Nm
approx. 44 Nm
Torque in steady state
condition
approx. 5 Nm
approx. 9 Nm
approx. 14.5 Nm
Response time 0-100 %
without load
approx. 120 ms
approx. 170 ms
approx. 190 ms
Current consumption of
whole governor
maximum current
safe current in
steady state condition
approx. 5 A
approx. 1.7 A
Storage temperature
-55°C up to +110°C
Ambiente emperature in
operation
-25°C up to +90°C
Ambiente temperature
special version
-40°C up to +90°C
Humidity
up to 98 %
Protection grade
IP 55
Weight without base
Weight of base
approx. 12.3 kg
approx. 1.3 kg
