5 Sensors
PRIAMOS I 9
5 Sensors
5.1 Overview
Sensor Speed
Coolant
Temperature
Oil Pressure Boost Pressure
HZM Designation IA .. TS 01-28-PT1000 DSO 01-6
DSO 01-10
DSO 01-16
DSL/G 0..-2
DSL/G 0..-5
DSL/G 0..-10
Connection SV 6-IA-2K
2 pole
SV 6-IA-2K
2 pole
DIN 43650 A
2 Line System
DIN 43650 A
2 Line System
Measuring Procedure inductive, active PT1000, passive active active
Measuring Range 50...6.000 Hz -50...+150°C 0...6 bar
0...10 bar
0...2 bar
0...5 bar
0...10 bar
Supply Voltage
Range
passive 10...34 V DC 12...36 V DC
Output Signal Range 0...10 V AC ca. 700...1500 Ohm 4...20 mA 4...20 mA
Operating
Temperature Range
-55...+120°C -50...+150°C -25...+125°C -40...+100°C
In order to ensure maximum flexibility with regard to the sensors, the minimum/ maximum
current values and the measuring ranges of the pressure and temperature sensors have been
provided programmable.
