14 Ordering Specifications
44 PRIAMOS I
14 Ordering Specifications
14.1 General
To know which informations we need, we have made a special order information for
digital governors. It has the No. DG 96 012-d. This form has to be filled in and send to
HEINZMANN together with the order.
14.2 Cable Length
It is of advantage to obtain the harness together with the governor.
It is not possible to use all signals simultaneous because some inputs and
outputs of the governor have various options depending on the application.
a) L1 = Control Unit - Power Supply
L 1.1 Control unit - power supply .............cm 5 x 1,50 mm²
b) L2 = Control Unit - Actuator
L 2.1 Control unit - actuator (feedback) .............cm 3 x 0,75 mm² shielded
L 2.2 Control unit - actuator (drive) .............cm 4 x 1,50 mm²
c) L3 = Control Unit - Setpoint Adjuster
L 3.1 Control unit - local setpoint .............cm 3 x 0,75 mm² shielded
L 3.2 Control unit - manual setpoint .............cm 2 x 0,75 mm²
L 3.3 Control unit - accessory unit 1 .............cm 2 x 0,75 mm² shielded
L 3.4 Control unit - accessory unit 2 .............cm 2 x 0,75 mm² shielded
d) L4 = Control Unit - Magnetic Pickup
L 4.1 Control unit - magnetic pickup 1 .............cm 2 x 0,75 mm² shielded
L 4.2 Control unit - magnetic pickup 2 .............cm 2 x 0,75 mm² shielded
Note
