11 Harness

40 PRIAMOS I

11.2 Plug Designations

Pickup IA ...

Actuator

StG 16-03/

StG 30-03/

StG 40-03

SV 103-DC-10 G (010-02-181-00)

SV 103-DC-19 SG (010-02-183-00)

SV 103-DC-19 PG (010-02-222-00)

SV 103-DC-24 SG (010-02-185-00)

SV 103-DC-24 PK (010-02-177-00)

SV 103-DC-19 SK (010-02-165-00)

SV 103-DC-19 PK (010-02-175-00)

SV 6-KG-10 K (010-02-044-00)

SV 6-IA-2 K (010-02-170-00)

SV 16-StG-5 KW (010-02-179-00)

SV 16-StG-5 G (010-02-039-00)

IIIIII

Control Unit DC 161 - 03

or DC 301 - 03

or DC 401 - 03

Figure 27: Plugs with Designation
