Operating instructions
Comfort controller KWL-BEC
10
GB
MENU – Auxiliary heating:
This menu item is only show if an extension module KWL-EM
has been connected and
recognised.
Active temperature profile
Displays which temperature profile is currently active.
(Display range 10 to 45 °C)
Setting temperature profile
The following temperature profiles can be selected:
– Standard 1 = Pre-defined temperature profile
– Standard 2 = Pre-defined temperature profile
– Fixed value = Target temperature
– Individual 1 = Individual custom temperature profile
– Individual 2 = Individual custom temperature profile
Temperature profile Duct temperature „Fixed value”
The target temperature can be set from min. 10 °C to max. 40 °C via the rotary encoder.
When extending the KWL unit with one or more humidity/temperature sensors, the minimum
(5
°C - 15 °C) and maximum (30 °C - 55 °C) duct temperatures must be set.
If only one duct sensor is installed for an auxiliary heater, the target temperature is the
selected
supply air temperature. When using one or more humidity/temperature sensors,
the desired
room temperature is the selected target temperature.
Edit individual temperature profile.
Different room temperatures
can be set for each weekday depending on time using the two
"individual temperature profiles".
Duct temperature Min-Temp./Max-Temp.
Before setting the individual temperatures, the minimum (5 °C - 15 °C) and maximum
(30 °C -
55 °C) duct temperatures must be determined.
