HELIX HLT3000 User Manual

2/ BEFORE YOU BEGIN
- 2 -
IMPORTANT: Read all instructions carefully. Assemble the Helix in accordance with
thestepsinthemanual.Layoutallpartsontheoorpriortoassemblytomakesure
you have all the parts listed below. In case of discrepancy, please contact Customer
Service at 888-435-4926 or service@helixco.com
PRE-ASSEMBLY CHECK LIST
Note: Some parts may be factory pre-assembled.
Item # Description Qty
1. Left and Right Stabilizer Legs 2
2. End Caps Front (F) Rear (R) 4
3. Pedal Assembly 2
4. Main Frame 1
5. Rubber Circle for Dome Cover 1
6. Computer 1
7. Center Upright Tube 1
8. Handlebar Right 1
9. Handlebar Left 1
10. Transport Plate Bolts 4
Item #Description Qty
11. Pedal Frame Bolts 8
12. Computer Mounting Bolts 4
13. Allen Head Tapered Upright Bolts 4
14. Computer Mounting Plate 1
15. Handlebar Allen Head Bolts 10
16. Computer Mounting Bolts 4
17. Water Bottle Holder 1
18. Water Bottle Holder Bolts 2
19. Dome Cover 1
20. Stabilizer Leveling Feet 4
21. Transport Plate Assembly 1
