PROGRAMMING
General Information
The control valve is the “brain” of your water lter. It consists of
the valve body and powerhead with solid state microprocessor.
The display panel (see Figure 5) consists of the LCD dis-
play and ve push buttons which are used in displaying and
programming the water lter settings.
Figure 5
USER DISPLAYS/SETTINGS
General Operation
When the system is operating, one of three
displays may be shown. Pressing NEXT will
alternate between the displays. One of the
displays is the current time of day. The sec-
ond display is one of the following: days to a
regen or gallons remaining. Days To A Regen
is the number of days left before the system
goes through a regeneration cycle. Capacity
remaining is the number of gallons that will
be treated before the system goes through a
regeneration cycle. The third display is current
ow in gal/min. The user can scroll between
the displays as desired by pushing NEXT or
display will scroll automatically.
When water is being treated (i.e. water is
owing through the system) the word "GPM"
ashes on left side of display when other than
ow rate is displayed.
Figure 6
➔
DAYS TO A REGEN
6
CAPACITY REMAINING
650
REGEN TODAY
GAL
NORMAL OPERATION SCREENS
PM
6:35
TIME OF DAY
GPM
6.8
FLOW RATE
➔
USER DISPLAY 1
Typical user
display. Shows
capacity or days
remaining before a
regeneration.
USER DISPLAY 2
Displays current time.
USER DISPLAY 3
Displays present ow
rate.
REGEN TODAY
ashes in upper left
corner of display
between rotating
display when RE-
GEN button pushed
once.
GPM
Flashes when the
turbine is rotating.
User screens will continuously scroll, switching
views every 3 seconds. If the screens are manu-
ally scrolled, this screen will remain constant for
5 minutes then continue to scroll. The condition-
al screens will take precedence over the scrolling
and the conditional conditions will apply.
OR
DEALER NAME
DEALER PHONE NUMBER
GPM
May display if service is required.
12:00
Regeneration Mode
Typically a system is set to regenerate at a time of low water usage. An example of a
time with low water usage is when the household is asleep. If there is a demand for
water when the system is regenerating, untreated water will be supplied. If water is
being used when regeneration starts, there may be a momentary delay in ow as old
head of air is being expelled from the system.
When the system begins to regenerate, the display will change to include information
about the step of the regeneration process and the time remaining for that step to be
completed. The system runs through the steps automatically and will reset itself to
provide treated water when the regeneration has been completed.
Manual Regeneration
Sometimes there is a need to regenerate the system, sooner than when the system
calls for it, usually referred to as manual regeneration. This is usually due to period of
heavy water usage.
To initiate a manual regeneration at the preset delayed regeneration time, press
and release “REGEN”. The words “REGEN TODAY” will ash on the display to
indicate that the system will regenerate at the preset delayed regeneration time.
If you pressed the “REGEN” button in error, pressing the button again will cancel
the request.
Figure 11
Regeneration Step #2
(shows time remaining in "Backwash" is 8:22)
Figure 7
To initiate a manual regeneration immediately, press and hold the “REGEN” button for three seconds. The system will begin to
regenerate immediately. The request cannot be cancelled. You must cycle all the way through the cycles to make it stop. PLEASE
NOTE: This will reset the meter.
