Hellenbrand ProMate 1 - System Specifications

28
Model PM1-024 PM1-032 PM1-032-10 PM1-048 PM1-064
Factory Regeneration Settings
Cycl e 1 Fill Minutes 3.0 4.0 4.0 6.0 8.0
Gallons 1.5 2.0 2.0 3.0 4.0
Cycl e 2 Softening Minutes 120 120 120 120 120
Gallons 0 0 0 0 0
Cycl e 3 Backwash Minutes 8 8 8 8 8
Gallons 10.4 13.6 17.6 17.6 25.6
Cycl e 4 Brine Dr DN Minutes 60 60 60 60 68
Gallons 13.8 16.2 16.2 19.2 38.8
Cycl e 5 Rinse Minutes 4 4 4 4 4
Gallons 5.2 6.8 8.8 8.8 16.8
Cycl e 6 Optional
Total Regen Gallons 30.9 38.6 44.6 48.6 85.2
*Calculations are based on factory low salt setting @ 3 5 psi
Lbs. Min. Lbs. Min. Lbs. Min. Lbs. Mi n. Lbs. Min.
2.5/1.7 3.3/2.2 3.3/2.2 5.0/3.4 6.6/4.4
4.5/3.0 6.0/4.0 6.0/4.0 9.0/6.0 12/8.0
7.5/5.0 10/6.7 10.0/6.7 15.0/10.0 20/13.5
11.3/7.5 15/10.0 15/10.0 22.5/15.0 30/20.0
10,000 13,200 13,200 20,000 26,400
17,100 22,800 22,800 34,200 45,600
21,000 28,000 28,000 42,000 56,000
23,730 31,500 31,500 47,250 63,000
9.8 10.1 11.3 10.5 14.2
13.1 13 14.5 14.1 18.2
8 lbs 11 lbs 14 lbs 14 lbs 20 lbs
0.75 1 1 1.5 2
8X44 9X48 10X44 10X54 12X52
18X33 18X33 18X33 18X40 18X40
3/17 3/17 3/17 3/26 3/26
NA NA NA NA NA
275 275 275 412 412
YES YES YES YES YES
474 474 474 474 474
NO NO NO NO NO
3/8" 3/8" 3/8" 3/8" 3/8"
1.3 1.7 2.2 2.2 3.2
0.5 0.5 0.5 0.5 0.5
VIOLET RED RED WHITE YELLOW
0.18 0.21 0.21 0.25 0.44
0.23 0.27 0.27 0.32 0.57
850 1,125 1,125 1,700 2,275
1" 1" 1" 1" 1"
3/4" 3/4" 3/4" 3/4" 3/4"
3/8" 3/8" 3/8" 3/8" 3/8"
3/4" 3/4" 3/4" 3/4" 3/4"
3/8" 3/8" 3/8" 3/8" 3/8"
** High Salting may require different grid height and/or larger brine tank
Factory default setting are shown in bold
Recommended minimum pipes sizes are copper pipe equivalent, when using PEX increase one nominal size
Hellenbrand products are not for sale or distribution into the State of California effective 8/21/18. 800870 REV C
5/13/19
Bri ne Line Si ze
DLFC (gpm)
High Capacity Resin (Cu. Ft.)
Capacity - Efficiency
Efficient - 4200 grains/lb
low Salt - 3800 grains/lb
Medium Salt - 2800 grai ns/lb
** Grid Height
Salt Storage Capacity lbs
BLFC on Valve
Safety Brine Valve
BLFC at Brine Tank
Stock Code Number
Shipping Weight (includes pallet)
BLFC (gpm)
Injector Si ze
Injector Draw Rate @ 35 psi (gpm)
Injector Sl ow Rinse Rate @ 35 psi (gpm)
Drain Line
Factory Meter Setting (for single unit)
Size of connections
Inlet / Outlet
Drain line
Brine Li ne
Brine Li ne
Recommended minimum pipe size
ProMate 1 Specifications
Resi n Tank Size
Mi n/Max sal t setting in Lbs
High Salt - 2100 grains/lb
Refil l Lbs / Minutes
Efficient salt @ 3.3 LBS
Low Salt @ 6.0 LBS
Medium Salt @ 10 LBS
High sal t @ 15 LBS
Servi ce Flow Rates
Peak @ 15 psi loss
Flint Underbed (Lbs)
Continuous @ 10 psi loss
Recommended Brine Tank Size
PROMATE-1
®
SYSTEM SPECIFICATIONS
