Quick Start Guide REX 100 WAN | WiFi
23
- Protection rating IP20
Certications CE, UL
UL UL 61010-1/ UL 61010-2-201
- Voltage supply
DC 24 V (18 ... 30 V DC, SELV and limited
energy circuit)
- Pollution degree 2
- Altitude Up to 2,000 m
- Temperature cable rating 87 °C
REX 100 WiFi (700-875-WIF01)
Dimensions (DxWxH) 32 x 59 x 76 mm
Weight Approx. 130 g
Number of inputs | type 2 | DC 24 V, as per DIN EN 61131-2 Type 2
WiFi interface
- Type
IEEE802.11b/g & 802.11n (1T1R mode), to
150 Mbps
- Frequency range
EU (2.412 GHz - 2.472 GHz, 1-13 Channel)
USA (2.412 GHz - 2.462 GHz, 1-11 Channel)
- Transmission speed
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: (20 Mhz) MCS0-7, up to 72 Mbps
802.11n: (40 MHz) MCS0-7, up to 150 Mbps
- Wireless security methods WPA/WP2, 64/128/152 bit WEP, WPS
LAN interface 4 x
- Type 10 Base-T/100 Base-T
- Connection RJ45 socket
- Transmission rate 10/100 Mbps
USB interface 2 x
- Protocol USB 2.0 host
- Connection USB A socket
Status indicator
4 LEDs function status
8 LEDs Ethernet status
Voltage supply DC 24 V, 18 ... 30 V DC
Current draw Max. 250 mA with DC 24 V
Environment requirements
- Ambient temperature 0 °C … +60 °C
- Transport and storage tem-
perature
-40 °C … +60 °C
- Relative air humidity 95 % r H without condensation
- Pollution degree 2
