2.1.5 Loading the Analyzer with
a Cuvette
The Loading position
FIGURE 2-6
FIGURE 2-6 shows the Analyzer with the
Cuvette holder(1) open, referred to as the
Loading position.
1 Cuvette holder
Inserting a Cuvette
1
FIGURE 2-7
Obtain a blood sample according to the
procedure described in section 3 Sampling
and Measuring.
a) Place the Cuvette in the Cuvette
holder(1) and gently close the Cuvette
holder.
The Analyzer will automatically start the
measuring procedure.
1 Cuvette holder
The Measuring position
1
FIGURE 2-8
FIGURE 2-8 shows the Analyzer with the
Cuvette holder(1) in the closed position,
referred to as the Measuring position.
1 Cuvette holder
