1.2.2 Analyzer overview
Front panel
FIGURE 1-3
The Analyzerī(1) is started when the On/Oī
buttonī(2) is pressed. The screen images will
be visible on the Displayī(3).
All navigation and information handling is
performed by pressing the appropriate touch
buttons directly on the Displayī(3).
To perform a measurement, the Cuvette is
ļ¬lled with sample material and placed in the
Cuvette holderī(4). The Cuvette holder is
inserted into the Analyzer.
To turn oī the Analyzerī(1), press the On/Oī
buttonī(2).
1 Analyzer
2 On/Oī button
3 Display
4 Cuvette holder
1
4
3
2
