Back panel
FIGURE 1-4
The following items are found on the back
panel of the Analyzer.
• Power inlet(1) for the Power Adapter
• Power + USB signal inlet(2) for
connection to the Docking Station
• Built-in Barcode Scanner(3)
• IR Transmitter/Receiver(4) for data
transfer to/from the Docking Station
The Power inlet(1) for the Power Adapter
can only be used when the Analyzer is out of
the Docking Station. When the Analyzer is
placed in a Docking Station, this inlet will be
blocked and the Analyzer receives power via
the Power + USB signal inlet(2).
1 Power inlet (for Power Adapter)
2 Power + USB signal inlet (for Docking Station)
3 Barcode Scanner
4 IR Transmitter/Receiver
