Technical data
User manual COMPACT-range 11
5 TECHNICAL DATA
Data per machine
COMPACTType
MINI MAXI Gastrovac Gastrovac
PRO
SUPER
Size and weight of the machine
Height mm 380 380 415 470 990
Width mm 330 330 415 550 535
Depth mm 460 460 520 580 655
Weight Kg 31 41 55 68
Size and weight of the packed machine
Length mm 500 580 700 700
Width mm 540 540 540 650
Depth mm 630 630 630 630
Weight Kg 36 46 65 83
Size of the vacuum chamber
Length mm 365 365 340 370 530
Width mm 280 280 320 420 455
Depth mm 130 130 135 170 110
Sealing configuration Net sealing length
1 x sealing beam mm 270 270 320 420 420
Vacuum pump
50 Hz m³/h 3 8 16 16 21Capacity
60 Hz m³/h 3.6 9.6 19 19 24
Final pressure mBar 15 2 2 2 2
Oil quantity Ltr 0,06 0,25 0,3 0,3 0,5
Weight vacuum pump Kg 5.1 10.3 18 18 19
50 Hz Db(A) 59 59 60 60 62Noise
60 Hz Db(A) 59 59 64 64 62
General data
Maximum leakage 0.1 mbar/s
Recommend kinds of oil With a surrounding temperature of
VM 068 5 - 12º C
VM 100 12 - 30º C
VS 100 or VC 101 30 - 40º C
Electrical connections
Tension, power, frequency See the identification
Maximum permissible voltage variance - 10% to + 10%
Ambient conditions
Ambient temperature + 5 to + 30º C
Transportation temperature - 25 to + 55º C
Humidity 30 % to 95 % (without condensation)
Positioning Inside, level, free of walls, ect,
• Voltage data was not included in this summary because these are dependent on the electricity
supply of the country that the machine is intended for. The voltage data are given on the machine
indentification plate.
• The useful space in the vacuum chamber depends on the number of sealing trays ant their
positioning. Each tray lessnes the useful space by about 50 mm.
• Sizes and weights are for the standard (simples) model machines.
