Hercules DJControl Inpulse 500 User Manual

5.4. Hardware mixing: inputs and outputs
Microphone input
MIC VOL: controls the microphone volume (hardware adjustment).
Light ring:
off = no audio signal / green = audio signal / red = audio signal
saturation.
2-band EQ: lets you adjust the HIGH (treble) and LOW (bass) frequencies for the
microphone.
Aux (auxiliary) input
AUX VOL: controls the volume for the Aux input (hardware adjustment).
Light ring:
off = no audio signal / green = audio signal / red = audio signal
saturation.
AUX FILTER: filter for the Aux input.

Hercules DJControl Inpulse 500 Specifications

General

Type	DJ Controller
Decks	2
Mixer Channels	2
Audio Interface	24-bit / 44.1 kHz
Crossfader	Yes
Compatibility	Windows, macOS
MIDI	Yes
Pitch Control	Yes
Built-in Sound Card	Yes
Performance Pads	8
Outputs	RCA (Master), 1/4" (Booth)
Inputs	RCA (Aux)
Software	DJUCED
Dimensions	540 x 250 x 70 mm
Weight	3.2 kg
EQs	3-band per channel
USB	1 x USB Type-B
Jog Wheels	2 (motorized)
