Hermann Supermicra 23 E - Chimney Systems and Flue Terminal Placement

15
Installation
for the technician
Chimney connections
SUPERMICRA E (natural draught)
Place here all necessary
advices according to national rules about
CHIMNEY CONNECTIONS of OPEN chamber boilers
PRODUCTS TEST POINT
2500 mm MAX
SLOPE
min 3%
2 x d
min
d
FLUE
NO YES
These diagrams are
to explain the most
important ITALIAN
laws concerning
chimney connections
(for EXEMPLE
purpose only)
