Chimney connections
SUPERMICRA SE (forced draught)
NOTE ON FLUE INSTALLATION
When fitting air inlet and flue outlet horizontal
ducts, it is necessary to make sure there is a slope
of 2÷5% downwards from the boiler to the out-
side (see diagram). This is essential to guaran-
tee correct boiler operation and reliability. Air in-
let and flue outlet terminals should be protected
by suitable approved flue accessories, to avoid
environmental elements penetration.
Place here all necessary
advices according to national rules about
CHIMNEY CONNECTIONS of sealed chamber boilers
FLUE
NO YES
2% ÷ 5%
631R01
