for the user
Boiler controls
To have the access to the boiler controls it is sufficient to push on
the lower part of the panel, as shown in the figure.
In addition to the controls in the front panel, we remind you that the
boiler must be equipped, during the installation process, with an
external general switch which totally disconnects the boiler from
the electrical supply.
Instructions for boiler ignition,
functioning and turning off
TO START THE BOILER
Open the gas tap and turn on the external general switch. The green lamp [1] flashes to show that
the boiler is supplied but not on (in stand-by). Turn the Selector [2] in the suitable position
SUMMER
or WINTER . The green lamp [1] will flash constantly to show that the boiler is
on.
ATTENTION: Do not activate the Chimneysweeper Function which is reserved for the
installer and which forces the ignition of the burner (the green lamp flashes rapidly). If, by
mistake, it should happen, bring immediately the selector in the central position (0), wait
until the green lamp flashes slowly, and then turn the selector in the desired position.
TO STOP THE BOILER (STAND-BY)
Turn the selector [2] in the central position (0).
If the boiler is off for a long period see the paragraph “INACTIVITY OF THE BOILER”
for the necessary precautions about the electrical supply, gas supply and anti freezing
protection.
71
23
4
5
6
CONTROL PANEL
