• Connect the cables following the number markings on the board and on the cables
• Replace the rear cover
Sequential Control Board Replacement
WARNING: Ensure that the machine is turned off
• To disconnect the machine’s power supply, pull the power plug out of the socket
• Open the front panel by removing the screws
• Disconnect all the cables and remove the electronic board
• Install the new electronic board and connect the cables following the number
markings on the board and on the cables
