26
Warning level
Below this level you are warned
to fill the canister
0,4 litres
Alarm level
Below this level dispensing is no
longer permitted
0,2 litres
Steps alarm
Number of motor steps possible
before proceeding with a
precautionary substitution
1.013.854.085 steps
(1.760,00 litres)
Purging alarm
Maximum time lapse without
purging, between one dispense
and another of the same
colourant
6 hours
Calibration Page
Drop Calibration
Minimum quantity calibrated
Threshold Calibration
Machine Calibration
The theoretical value of the product moved (pumped) with one complete rotation of the
pump is 0,6944 cc, measured with water at an approximate temperature of 25 °C.
576,05346 steps of the motor are necessary to dose 1cc. This value is programmed in the
dispenser as being the standard calibration value.
