HERO GLAMOUR - Rear Wheel

47
(12) Lug (13) Slot
12
13
•
After installing wheel, apply the brake
several times and check for free wheel
rotation when released.
•
Adjust the front brake free play (page 42).
Removal
•
Remove the rear brake adjusting nut (1)
and disconnect the brake rod (2) from the
brake arm (3) by pushing down the brake
pedal. Disconnect the brake stopper arm
(4) from the brake panel (5) by removing
split pin (6) and lock nut (7).
Axle nut torque: 5.2 Kgf-m
(c) Rear wheel
•
Support the vehicle securely on the main
stand and raise the rear wheel off the ground.
•
Tighten the axle nut.
•
Reverse the removal procedure.
•
Install the front wheel by ensuring that the
lug (12) on the left fork is located in the slot
(13) in the brake panel.
Installation
3 5
7 6 4
(1) Rear brake adjusting nut (2) Brake rod
(3) Brake arm (4) Brake stopper arm
(5) Brake panel (6) Split pin (7) Lock nut
•
Pull out the axle (9) and collar (10).
•
Remove the rear axle nut (8).
•
Remove the wheel.
(8) Axle nut (9) Axle (10) Collar
•
Reverse the removal procedure
2.2 kgf-m
Axle nut torque: 5.2 kgf-m.
Brake stopper arm nut torque:
Rear wheel installation
9
1 2
8
10
