4. Remove the axle nut (7).
2. Remove the speedometer cable (1) by
pressing the tab (2) & then pull out the
cable
3. Disconnect the brake cable (3) from
brake arm (4) and brake panel (5) by
removing the front brake adjusting nut (6).
5. Remove the axle then remove the wheel.
1. Raise the front wheel off the ground.
Drum Type (Cast wheel version)
(1) Speedometer cable (2) Tab (3) Front
brake cable (4) Brake arm (5) Brake panel
(6) Front brake adjusting nut (7) Axle nut
Switch on the ignition, rotate the front
wheel and see if speedometer needle is
working.
5.4 kgf-m
5
6
7
