22
ESSENTIAL INDIVIDUAL COMPONENTS
IGNITION SWITCH
The ignition switch (1) is on the right side
below the steering.
(3) Steering lock position
(2) Ignition key
(1) Ignition switch
1
3
“LOCK” Position
The engine can be started, Turn signal
indicators, Horn, Tail/Stop lamp and Fuel
gauge will be functional.
Steering can be locked.
Engine cannot be started and no electrical
system will be functional.
“LOCK”
Key position
Function
Key cannot be removed
Key can be removed
Key can be removed
Key removal
2
“ON” ( )
Position
“OFF” ( )
Position/Lock Open
“ON” ( )
“OFF” ( )
