5
When the transmitter is turned on, it performs a
self-test to be sure that the circuitry is within
designated parameters. If an error is detected, the
transmitter will not transmit any motion signals.
The BMS-2 receiver display will show "0 0 4" indicating
a passive E-Stop condition in the transmitter.
Receiver Safe Mode
The following conditions cause the receiver to go into
its Safe mode:
• Radio signal interference
• Transmitter out of operating range
• E-Stop button is activated
• E-Stop circuit failure
• Low battery sends E-stop after time out
When the transmitter is turned off, the Time Out
process begins. The Time Out period is set to 450
msec at the factory. If the receiver does not establish
contact with the transmitter within that time period, it
goes into the Safe Mode. In Safe Mode, the receiver
shuts off power to the output modules and activates the
E-stop function.
The BMS-2 receiver display will show "0 0 1" indicating
an E-Stop condition in the receiver.
NOTE: For descriptions of other display codes, see the
Operation Section of this manual, the Diagnostic
Display Codes table on page 16, or the technical
documentation supplied with your radio remote control
system.
SAFETY ALERTS
Look for this symbol to point out
important safety precautions. They
mean:
Attention!
Personal Safety Is Involved!
Become Alert!
Obey The Message!
The safety alert symbol is used in decals on the unit
and with proper operation procedures in this manual.
Understand the safety message. It contains important
information about personal safety on or near the unit.
NOTATIONS
NOTE: General reference information for proper
operation and maintenance practices.
IMPORTANT: Specific procedures or information
required to prevent damage to unit or attachment.
PRACTICES AND LAWS
Practice usual and customary safe working
precautions, for the benefit of yourself and others.
Understand and follow all safety messages. Be alert to
unsafe conditions and the possibility of minor,
moderate, or serious injury or death. Learn applicable
rules and laws in your area.
REQUIRED OPERATOR TRAINING
Original purchaser of this unit was instructed by the
seller on safe and proper operation. If unit is to be used
by someone other than original purchaser; loaned,
rented or sold, ALWAYS provide this manual and any
needed safety training before operation.
ALWAYS review the operators manual of any machine
to be controlled by radio remote control.
POSSIBLE SOURCES OF DANGER
This system makes remote control via radio signals
possible. However, the transmission of control
commands can take place around obstacles and out of
the operator’s direct sight. To prevent accidental
start-up and possible injury or damage:
1. Always engage the E-stop button and switch
"OFF" the transmitter when it is not in use.
Remove the key if the unit is placed any distance
away from the operator.
2. Disconnect the power supply from the receiver
before any assembly, maintenance or repair work
is done.
IMPORTANT: AVOID SYSTEM DAMAGE - ALWAYS
disconnect receiver power supply and control wiring
before welding on any part of the crane/machine
3. Never remove or alter any of the safety features
of this system.
4. ALWAYS be sure the crane/machine and radio
remote control Emergency-Stop functions work
properly before beginning any crane/machine
operation.
SAFETY
DANGER: IMMINENTLY HAZARDOUS
SITUATION! If not avoided, WILL RESULT in
death or serious injury.
WARNING: POTENTIALLY HAZARDOUS
SITUATION! If not avoided, COULD RESULT
in death or serious injury.
CAUTION: POTENTIALLY HAZARDOUS
SITUATION! If not avoided, MAY RESULT in
minor or moderate injury. It may also be used
to alert against unsafe practices.
