5 Measurement
5.1 Active energy Measurement
◼ Import active energy total and per tariff
◼ Export active energy total and per tariff
◼ Sum active energy total and per tariff
◼ Net active energy total and per tariff
◼ Import active energy in L1
◼ Export active energy in L1
◼ Import active energy in L2
◼ Export active energy in L2
◼ Import active energy in L3
◼ Export active energy in L3
5.2 Reactive energy Measurement
+R=R
I
+R
II
;-R=R
III
+R
IV
◼ Import reactive energy total and per tariff
◼ Export reactive energy total and per tariff
◼ Reactive energy total and per tariff in QI
◼ Reactive energy total and per tariff in QII
◼ Reactive energy total and per tariff in QIII
◼ Reactive energy total and per tariff in QIV
◼ Import reactive energy in L1
◼ Export reactive energy in L1
◼ Import reactive energy in L2
◼ Export reactive energy in L2
◼ Import reactive energy in L3
◼ Export reactive energy in L3
5.3 Apparent energy Measurement
◼ Import apparent energy
◼ Export apparent energy
◼ Import apparent energy in L1
