User manual for poly-phase meter
52
Standard Compliance
IEC62052-11,
IEC62053-22,
IEC62053-23 or IEC62053-24,
EN50470-1,
EN50470-3,
Mechanical parameters
Connection type
Indirect connection
Network type
3P4W or 3P3W
Terminal configuration
L1L1L2L2L3L3NN (3P4W)
or
L1L1L2L2L3L3 (3P3W)
Weight of Meter
1.28 kg
Dimension(H x W x D)
Long terminal cover:
245mm×175mm×88.5mm
Or Extra Long terminal cover:
284.9mm×175mm×88.5mm
Mounting
Front projection mounting
Sealing
Sealing provisions for terminal with sealing screw
Terminal hole diameter
6.9mm x6.0mm
Terminal cover
Long terminal cover or
Extra Long terminal cover or
Short terminal cover
Meter Cover material
PC+10%GF
Meter Base material
PC+10%GF
Terminal Cover
material
Transparent PC
Technical parameters
Default display range
0~999999.99 kWh
Display mode
LCD
