Harrington Generators International
498-1084 10 HRD060D Diesel Generator
Safety
On side panels near
base.
Qty. 4 off.
Label No: 499-1081-005
FORK LIFT POINT
The generator can be lifted from the sides or
from the front or rear using a fork lift truck with
correctly spaced forks.
It is intended that when lifting from the sides,
that one fork passes through the part of the
frame that forms a loop and foot.
On control panel and
generator base Qty 2
Label No: 499-1081-006
EARTH POINT
An M8 brass earth stud is supplied next to
the output sockets for the external earth
connection.
On the panel that can be
removed to gain access
to the oil dip stick.
Qty. 1.
Label No: 499-1081-007
CHECK ENGINE OIL LEVEL DAILY
The oil level should be seen on the oil dip stick
as per the diagram on the label.
On Fuel Filler Cap.
Qty. 1.
Label No: 499-1081-008
DIESEL FUEL ONLY
This generator must only be lled with
commercial diesel fuel containing up to 5%
bio-fuel. If special grades of diesel e.g. 100%
Bio-Diesel are to be used consult HGI rst to
discuss its suitability.
On Control Panel around
the DC Isolator Switch
Qty 1
Label No. 499-945-012
DC ISOLATOR IDENTIFICATION
Informational label showing the ON / OFF posi-
tions of the switch.
Next to exhaust outlet.
Qty. 1
Label No: 499-1081-010
CAUTION HOT EXHAUST
The exhaust pipe is shielded as much as is
practical but the nal outlet is hot.
