Harrington Generators International
498-1084 24 HRD060D Diesel Generator
Operation
AMF Installations
WARNING
Installation of the generator is to be made by
qualied personnel in accordance with appropriate
regulations e.g., Electricity Safety, Quality and
Continuity Regulations 2002 (S.I. 2002/2665), and
Electrical Safety regulations cited previously in this
document.
During the installation the AMF panel will need to be
connected to the remote connection socket on the
control.
Once connected
1. Press the red Reset Button
on the Engine
Control module on the generator control panel.
2. Press the white Auto
button on the generators
DSE3110 control module.
The AMF panel will then control the starting and
stopping of the generator.
Shutdown Protections
The generator is tted with the following protection
devices that will shut down the generator in the event
of a fault. They are indicated by LED’s on the engine
control module: The warning siren will also sound.
Over-Crank
Operates if the engine is cranked continuously for
more than 10 seconds and the engine fails to start.
This is to help prevent damage to the starter motor. If
the engine fails to start after three attempts investigate
the cause.
Low Oil Pressure
Operates if the oil pressure falls below a safe level.
This can be caused by a lack of oil, wrong type of oil
or high temperature. Check and top up the oil level as
necessary. During starting, the alarm is held off for 18
seconds to allow the oil pressure to build up to normal
running level. The engine will not crank if there is a
“low oil” pressure signal prior to starting.
Low Fuel Level
Check and top up the fuel as necessary. The engine
will not crank if a low fuel alarm is present. DO NOT let
the engine run out of fuel as the fuel system may have
to be bled before it will restart. The control module
can be set by a small switch on the back to sound an
alarm AND shut down on low fuel or just sound an
alarm.
