6.4 Default mode
Fig6.4..Default mode model
In this mode, WIFI enable, module works in the AP mode, ETH1, ETH2 function
enable. ETH1 works as WAN, ETH2 works as LAN. Through the appropriate settings,
the data between COM1 and network can achieve mutual conversion.
WIFI safety: support all encryption methods at present.
In this mode, WIFI device can connect with the module and become the device
under WIFI LAN.
WAN default IP is dynamic IP address. LAN, WIFI for the same local area network,
enabled by default DHCP server.
There are four mode for serial-net conversionTCP ServerTCP ClinetUDP
ServerUDP Client
TCP Server
Fig6.4.1.TCP Server
In this mode, the module is listening on the specified port, waiting for TCP Client
connection, if connected, all TCP data is sent directly to the serial port end, the data of
HLK-RM04
TCP Server
TCP
Client
TCP
Client
TCP
Client
DHCP ENABLE
SERIAL
HLK-RM04 MCU
WIFI CLIENT
(PHONEpad)
COM1
WIFI
AP
ETH2
ETH1
LAN
WAN
