Installation & Adjustments Predator SS Turntable Stretch Wrapper Operation Manual
Highlight Industries, Inc. ● 2694 Prairie SW, Wyoming, Mi 49519 ● 1-800-531-2465 21
Highlight Recommended Configuration Values:
Note
Changing the scale parameters to values other than the Highlight recommended
values may result in poor scale operation.
Highlight
Recommended
Value
Specifies the number of full-scale graduations. Value
should be consistent with legal requirements and
environmental limits on the useful system resolution.
Span Gain is related to A/D integration time. The larger the
span gain, the higher the internal resolution, but the slower
the update speed. Note that the scale must be re-
calibrated whenever this parameter is altered. See
Appendix C in the scales manual for more information.
Selects the range within which the scale will automatically
zero. Note that the scale must be in a standstill to zero the
scale.
Selects the range within which the scale may be zeroed.
Note that the indicator must be in standstill to zero the
scale.
Sets the level at which motion is detected by comparing
the present display update with the previous one. If motion
is not detected for two seconds or more, scale is in
standstill and can process a Print or Zero command.
Maximum value varies depending on local regulations
Averages weight readings to produce higher stability but
the slower the indicator’s response time. Choose 8 unless
a very fast response is needed.
Selects the desired formula which determines the point at
which the indicator shows overload. All selections are
based on the primary unit selected in F8.
Selects the primary base unit to be used in the calibration
process. Also the default unit for normal operation. 1 =
pounds, 2 = kilograms.
Determines the desired weight increments. Value should
be consistent with legal requirements.
Determines the location of the decimal point.
Places the scale in a Zero Calibration routine.
Places the scale in a Span Calibration routine. See below.
