Maintenance Predator SS Turntable Stretch Wrapper Operation Manual
Highlight Industries, Inc. ● 2694 Prairie SW, Wyoming, Mi 49519 ● 1-800-531-2465 33
Figure 9: Film Carriage Lift Chain Adjustment
Sprockets and Chains
All sprockets should be inspected for wear, and chains should be checked for proper
tension and lubrication on a periodic basis. Failure to do so will lead to premature sprocket
failure. Any general-purpose chain lube should be sufficient for lubrication. Replace chain
guards when preventative maintenance is complete.
Film carriage raise/lower chain
Threaded rod
Tensioning nuts
Bracket attached to backside
of carriage receiver
Bracket attached to backside
of carriage receiver
Tensioning nut
Threaded rod
Film Carriage raise/lower
chain
