Operation Instructions Predator SS Turntable Stretch Wrapper Operation Manual
Highlight Industries, Inc. ● 2694 Prairie SW, Wyoming, Mi 49519 ● 1-800-531-2465 27
Follow the procedure below to thread the film onto the Film Carriage.
Warning!
Be sure the Emergency Stop button is pressed before threading the film and
while the film is being threaded.
1. Place the film on the film mandrel.
2. Set the Stretch Handel to the OFF position to release the tension. (See figure below)
Figure 7: Film Loading/Threading Diagram
3. Follow the Film Feed Diagram and thread the 6-foot film tail ALL THE WAY though
the rollers.
4. After threading, rotate the Stretch Tension Knob clockwise to increase film tension;
or counterclockwise to decrease film tension.
Stretch Tension
Adjustment Knob
Stretch Tension
Indicator
Stretch Handle
(in off position)
