Highlight Predator SS - Mechanical Assembly Drawings

Technical References Predator SS Turntable Stretch Wrapper Operation Manual
Highlight Industries, Inc. ● 2694 Prairie SW, Wyoming, Mi 49519 ● 1-800-531-2465 49
Electrical Parts List
Machine
Section
HLI Part
Number
Item Description
Qty
1
401495
MICROPROCESSOR CARD
1
2
401361
TRANSFORMER CARD
1
3
401362
FUSE, 250 VAC, 1 AMP, GMA
2
4
401363
EPROM
1
5
403261
FUSE, 250 VAC, 10 AMP, GMA
2
6
401365
FUSE, 250 VAC, 5 AMP, GMA
2
7
401366
RELAY LY2 DC24V
5
11
401367
BUTTON WHITE
1
12
401368
BUTTON SEAT CONTACTOR Nox1
1
13
400609
400610
400611
AUTO RUN GREEN LAMP: COVER
SEAT
LIGHT
1
1
1
14
401371
KNOB RN-99F,ø6.4
2
15
400649
VARIOUS RESISTOR 5K
2
16
401372
EMG. SWITCH
1
17
401373
BUTTON SEAT CONTACTOR NCx1
1
18
401374
MAIN POWER SWITCH
1
21
400639
LIMIT SWITCH TZ-8108
2
22
400636
LIMIT SWITCH TM-1307
1
23
400641
PROXIMITY SWITCH PS-05N-3M
1
24
400637
LIMIT SWITCH TZ-7110
1
25
400643
PHOTO SENSOR A3R-2MX(OPTION)
1
26
404261
FAN, 80MM, 110-120VAC
1
27
404262
FUSE HOLDER
1
28
404263
FUSE, 0.2A, 30MM
1
N/S
310008
BUTTON MEMBRANE LABEL FOR CONTROL PANEL
1
N/S
403409
CARRIAGE CONTROL CABLE
1
