27
500013
PROXIMITY SWITCH FIX SEAT
1
28
200103
SCREW M4x20L
2
29
200128
NUT M5
6
30
300013
300014
BELT B-172

1.5M
BELT B-183

1.8M
1
1
31
200113
SCREW M8x25L
4
32
500004
500005
TURNTABLE PLATE 1.5M
TURNTABLE PLATE 1.8M
1
1
33
200084
SCREW M8x20L
4
34
500007
WHEEL 22”
1
35
500006
LOCATING PLATE
1
36
200108
SCREW M5x10L & W.
4
37
500008
PULLEY FIXING PLATE
1
38
500085
BELT PULLEY SEAT RING
1
39
300012
RING RTW-42
1
40
500084
BELT PULLEY SHAFT
1
41
300018
BEARING 6004ZZ
2
42
300010
RING STW-20
1
43
500086
BELT PULLEY BEARING SEAT
1
44
200088
SCREW M10x16L
4
45
200100
SCREW M4x8L & W.
4
46
500081
500082
MOTOR COVER

1.5M
MOTOR COVER

1.8M
1
1
47
600028
600029
TURNTABLE MOTOR BOX 1.5M
TURNTABLE MOTOR BOX 1.8M
1
1
48
200100
SCREW M4x8L & W.
2
49
600038
RAMP (FOR 60” TURNTABLE - NOT SHOWN)
OPT
50
600039
RAMP PORCH – 24” (FOR 60” TURNTABLE - NOT SHOWN)
OPT
51
602297
RAMP PORCH – 48” (FOR 60” TURNTABLE - NOT SHOWN)
OPT
